BFT ELI 250 N BT In-Ground Swing Gate Motor

The BFT ELI 250 N BT uses magnetic limit switches to detect the open and closed positions of the gate. Small magnets are positioned on the gate arm or pivot mechanism, and Hall-effect sensors inside the motor housing detect when the magnet passes, triggering the motor to stop at precisely the correct position. This differs from work-time limits (used on ATHOS AC motors, which stop after a timed run) and absolute encoders (used on the E5 BT A18, which continuously track position). Magnetic limits are well-suited to underground motors because they are sealed within the IP67-rated housing, immune to the dust, water, and moisture present in underground installations in Abu Dhabi’s varied ground conditions.

U-Link is BFT’s proprietary two-wire communication protocol that enables direct digital communication between the ELI 250 N BT motor and the THALIA control unit. Unlike traditional control boards that use separate wires for each function (open, close, stop, limit), U-Link transmits all motor data and commands over a single two-wire connection. This reduces wiring complexity significantly in underground installations where cable routing through the foundation is difficult. U-Link also enables the THALIA board to receive real-time feedback from the ELI motor — including D-Track obstruction data, slowdown position signals, and motor status — allowing more responsive and intelligent gate management than conventional wiring allows.

The ELI 250 N BT kit contains one in-ground motor only (product code P930125 00001). For a complete double-leaf gate installation you will additionally need: a second BFT ELI 250 N BT motor for the other gate leaf, a THALIA control unit compatible with 24V in-ground operators, a foundation box for each motor (BFT supplies the appropriate underground housing), a pair of photocells, a flashing light, remote controls, and drainage preparation at each motor position. Professional planning of the foundation box depth, drainage gradient, and U-Link cable routing is essential before any concrete work begins. Contact POWERgate Abu Dhabi on WhatsApp (+971 50 884 4933) before ordering to confirm your complete parts list and installation requirements.

The BFT ELI 250 N BT opens gate leaves to a maximum of 120° from the closed position — 10° wider than the BFT ATHOS AC range (110° maximum). For Abu Dhabi driveways where vehicles need to pass at a wide angle, or where the gate posts are positioned close to the property boundary requiring a wider opening arc for full clearance, the 120° capability is a practical advantage. At a 15-second cycle time, the ELI 250 N BT reaches its 120° open position smoothly with the built-in slowdown function decelerating the gate leaf before it reaches its magnetic limit stop, reducing mechanical stress on the hinge and foundation box at the end of each cycle.

The BFT ELI 250 N BT carries a 24-month manufacturer warranty from purchase covering material and workmanship defects under normal conditions. For an underground motor, warranty is particularly at risk from: inadequate foundation box drainage causing water accumulation that exceeds the IP67 rating’s 1-metre immersion threshold over extended periods; incorrect U-Link wiring damaging the motor’s communication interface; and misaligned magnetic limit switch magnets preventing clean position detection and causing the motor to over-travel. The motor’s -20°C to +50°C operating range and IP67 rating cover Abu Dhabi conditions when installation is correct. All warranty claims are handled locally by POWERgate Abu Dhabi — contact us on WhatsApp (+971 50 884 4933) or at sales@powergatead.com.
