PROTECO MEKO 8 800 KG Sliding Gate Motor

Product Overview

PROTECO MEKO 8 Motor is an electromechanical gear motor for rack-driven sliding gates up to 800 kg in Abu Dhabi. It is designed for residential and light commercial gate automation where a compact structure, quiet movement, and reliable mechanical performance are required. The MEKO range features a slim design, built-in control board with obstacle detection, plug-in radio receiver support, and an adjustable ground plate for easier installation. The MEKO 8 version is a 230V model with mechanical limit switch operation and IP44 protection, making it suitable for outdoor sliding gate automation.

Key Features and Technical Specifications

• Brand: PROTECO
• Product range: MEKO
• Product model: MEKO 8
• Product type: Electromechanical gear motor for rack-driven sliding gates
• Maximum gate weight: 800 kg
• Power supply: 230V ~ 50Hz
• Driving system: Rack
• Limit switch: Mechanical
• Current: 1.2–2 A
• Motor power: 300 W
• Capacitor: 10 µF
• Thermal protection: 150°C
• Maximum thrust: 440 N
• IP protection class: IP44
• Motor speed: 1400 rpm
• Opening speed: 10.5 m/min
• Duty cycle: 40%
• Dimensions: 310 x 195 x 310 mm
• Gear system: Irreversible gearing system
• Control board: Embedded control board with obstacle detection
• Receiver support: Plug-in radio receiver
• Ground plate: Adjustable horizontally and vertically
• Release system: Key-lock manual release system
• 24V battery-powered operation: Available only on 24V MEKO range, not specified for MEKO 8

Use Cases

• Residential sliding gates
• Villa entrance gates
• Apartment block gate automation
• Light commercial access gates
• Parking entrance sliding gates
• Warehouse sliding gate automation
• Rack-driven sliding gates requiring up to 800 kg motor capacity

Compatibility and Installation Notes

The PROTECO MEKO 8 Motor is compatible with rack-driven sliding gates up to 800 kg when the gate structure, track, wheels, rack, foundation, end stops, and 230V electrical supply are correctly prepared. The gate must move smoothly without obstacles before automation, and the motor should be installed with proper earthing, limit switch positioning, photocell safety devices, and control board programming. Professional installation is recommended to ensure safe force settings, correct rack alignment, reliable obstacle detection, and long-term motor performance. For technical installation checks, refer to the official PROTECO MEKO manual. (proteco.net)

Packing Includes

• 1 x MEKO gear motor
• 1 x MPIS05 anchor plate
• 1 x MGR0840Z grub screw 8 x 40
• 1 x MVI3995E screw 3.9 x 9.5 for cover
• 1 x MVI1050CZ screw Ø10 10 x 50 for motor-anchor plate fixing
• 1 x MRO10Z washer Ø10 for motor-anchor plate fixing
• 1 x MDAM10Z nut Ø10 for motor-anchor plate fixing
• 1 x MPC06 cable grommet SH70
• 1 x MTP22 slot-cover
• 1 x MGR0610Z limit bracket fixing screw 6 x 10 for B102 metal rack only
• 1 x MVI0510BZ screw TC 5 x 10 for cable-block
• 1 x MBC01 black cable block
• 1 x MVI4895DZ self-tapping screw 4.8 x 9.5 for lug
• 1 x MFAG01 yellow lug for earth system
• 1 x MMA02 limit-switch tip
• 1 x Release key
