SOMMER twist XL Swing Gate Operator

The SOMMER twist XL matches the NICE TOONA 7 TO7024 at 7m for the longest surface-mounted swing gate leaf in the POWERgate Abu Dhabi range. On weight, the NICE TO7024 handles up to 1,700 kg and the NICE TO6024HS handles 1,450 kg, both exceeding the twist XL’s 1,100 kg. For a 24V screw-type operator, 1,100 kg is a very high weight capacity. The SOMMER twist XL is the heaviest-duty motor in the SOMMER range by a significant margin, suited to Abu Dhabi estate gates, commercial compound entrances, and large industrial-style private properties.

Yes — the SOMMER twist XL’s 20mm/s maximum thrust speed is the fastest of any SOMMER motor in the POWERgate Abu Dhabi range. The twist 200 E and twist M both operate at 16.5mm/s. The additional 3.5mm/s on the twist XL is a deliberate design choice for a large heavy-gate operator: despite driving a 7m leaf at 1,100 kg, the higher rod speed reduces the total cycle time compared to running the same length stroke at 16.5mm/s, maintaining reasonable opening times for gates at the upper limit of the range.

The SOMMER twist XL specifies installation compatibility for both DIN left and DIN right gate configurations. DIN (Deutsches Institut für Normung) is a German standard system for specifying the handing of gates and doors viewed from the operating side. DIN left means the hinge is on the left as you approach the gate from outside; DIN right means the hinge is on the right. The twist XL’s universal DIN left/right compatibility confirms a single operator model handles both gate configurations without modification, simplifying specification for Abu Dhabi double-leaf or single-leaf gates of either handing.

The SOMMER twist XL’s 100% gate filling rating confirms it handles completely solid gate panels with no open sections — the maximum possible wind resistance for any gate leaf. Combined with a 10% maximum inclination tolerance, the twist XL is designed for demanding real-world installation conditions: sloped Abu Dhabi driveways up to 10% gradient and fully solid panels that create high wind loading. These ratings together confirm the twist XL as a genuine heavy-duty outdoor operator for the most challenging Abu Dhabi large-gate sites, including exposed compound perimeters and estate entrances.

The SOMMER twist XL carries a 24-month manufacturer warranty. The kit supplies one operator with post fitting and gate leaf fitting only — the control unit must be ordered separately. SOMMER offers compatible control units in its range; the correct model must be confirmed to support the twist XL’s 24V DC motor, ED 40% S3 duty, and SOMloq2 868.95 MHz radio. Safety photocells, flashing light, remote controls, and mechanical stops are also separate. At 7m and 1,100 kg, gate structural assessment by a qualified engineer is strongly recommended before installation. Contact POWERgate Abu Dhabi on WhatsApp (+971 50 884 4933) or sales@powergatead.com.
