Product Overview
Ditec ION B Motor is a 24V electromechanical sliding gate automation range for Abu Dhabi customers who need reliable control for residential, condominium, and light commercial gate entrances. The range includes ION4B for gates up to 400kg and ION6B for gates up to 600kg. Both models feature a built-in LCU50DC control panel, virtual encoder stroke control, bi-frequency radio receiver, Bluetooth, adjustable speed, and obstacle detection. With intensive-use testing, energy-saving standby performance, and configurable control functions, Ditec ION B is built for smooth, safe, and practical sliding gate operation.
Key Features and Technical Specifications
- Official product range: Ditec ION B
- Models: ION4B and ION6B
- Gate type: Sliding gate automation
- Maximum leaf weight: 400kg for ION4B; 600kg for ION6B
- Maximum opening width: 20m
- Motor technology: 24V electromechanical actuator
- Stroke control: Virtual encoder
- Control panel: Built-in LCU50DC
- Radio module: RCB100E
- Radio frequency: 433.92MHz / 868.35MHz selectable
- Bluetooth: Built-in
- Power supply for ION4B: 100V AC – 240V AC, 50–60Hz
- Power supply for ION6B: 100–120V AC / 200–240V AC selectable by switch, 50–60Hz
- Opening and closing speed: 0.1 – 0.3m/s
- Thrust: 600N pickup current for ION4B; 800N pickup current for ION6B
- Release system: Key-operated manual opening
- Service class: Intensive use
- Tested cycles: Up to 150,000 cycles
- Cycles per hour: 40 at 25°C
- Continuous cycles: 56 at 25°C
- Intermittence: S2 = 60 minutes; S3 = 70% at 25°C
- Operating temperature: -20°C to +55°C
- Operating temperature with NIO enabled: -35°C to +55°C
- Protection rating: IP44
- Accessory power supply: 24V DC / 0.3A
- Configurable outputs: 2 x 24V DC outputs
- Energy saving: Less than 0.6W for ION4B and less than 0.8W for ION6B
- Adjustable opening and closing thrust
- Adjustable speed
- Adjustable Soft Start and Soft Stop
- Adjustable automatic re-closing time
- Adjustable pre-flashing time
- Integrated datalogging with counter and recent alarm history
- Dynamic Obstacle Detection system
- Ready for optional magnetic limit switches
- Optional battery kit compatibility: BBK750X2
- Optional emergency release compatibility: ASR2 and IONSBM
Use Cases
- Residential sliding gates
- Villa entrance gates
- Condominium gate automation
- Commercial entrance gates
- Parking access gates
- Light commercial sliding gates
- Medium-duty access control points
- Properties requiring adjustable speed and obstacle detection
Compatibility and Installation Notes
The Ditec ION B Motor range is suitable for sliding gates up to 400kg with ION4B and up to 600kg with ION6B, with a maximum opening width of 20m. Correct installation requires proper gate alignment, stable foundations, accurate rack positioning, safe electrical wiring, force adjustment, and functional safety devices. Professional installation is strongly recommended because wrong mounting, incorrect force settings, or poor safety-device integration can create serious operating risks. Installers should review the official Ditec technical manual before commissioning, wiring, and safety testing.
Packing Includes
- Ditec ION4B or ION6B sliding gate operator, depending on selected model
- Built-in LCU50DC control panel
- Built-in RCB100E radio module
- Built-in Bluetooth module
Why Buy from POWERgate Abu Dhabi
POWERgate Abu Dhabi supplies dependable sliding gate automation products with local product guidance, technical support, and practical after-sales assistance for Abu Dhabi buyers. We help customers select the right motor capacity, compatible accessories, and installation approach for safe long-term gate performance.
Buy Ditec ION B today from POWERgate abu dhabi. Call/WhatsApp: +971 50 884 4933 or email us: sales@powergatead.com.
