NORTECH PD232 Dual Channel Loop Detector

Product Overview

NORTECH PD232 Loop Detector is a dual channel inductive vehicle detector designed for automatic gates, parking barriers, motorised doors, and access control systems in Abu Dhabi. It detects vehicle presence through two independent loop coils installed under the road surface, helping control safe opening, closing, and traffic direction. The PD232 model is part of Nortech’s 3-Series dual channel loop detector range and operates on 230V AC power. With selectable sensitivity, A-B logic, permanent presence mode, loop isolation protection, and diagnostic capability with DU100, it is suitable for reliable vehicle detection in busy residential, commercial, and industrial automation sites.

Key Features and Technical Specifications

• Brand: NORTECH
• Product range: 3-Series Dual Channel Loop Detectors
• Model: PD232
• Product type: Dual channel inductive loop vehicle detector
• Detection method: Two independent inductive loops buried under the road surface
• Power requirement: 230V AC ±15%, 48–60Hz
• Power consumption: 1.5VA max @ 230V
• Self-tuning range: 20–1000μH
• Sensitivity: 4-step selectable per channel
• Sensitivity levels: High 0.02% ΔL/L, Medium High 0.05% ΔL/L, Medium Low 0.1% ΔL/L, Low 0.5% ΔL/L
• Frequency: 4-step adjustable, 20–70kHz, determined by loop geometry
• Output relays: 1 output relay per channel, fail-safe
• Relay rating: 5A @ 230V AC, N/O contact per channel
• Pulse output duration: Approx. 150ms, factory option 250ms
• Presence time: Selectable limited or permanent presence
• Limited presence: 1 hour for 3% ΔL/L
• Operating modes: Presence CH1, pulse CH1, presence CH2, pulse CH2, A to B CH1 and B to A CH2
• Automatic Sensitivity Boost: Switch selectable
• Protection: Loop isolation transformer, zener diode clamping on loop inputs, and gas discharge tube protection
• Diagnostic capability: Compatible with DU100 diagnostic unit
• LED indicators: Power LED and individual channel LEDs
• Operating temperature: -40°C to +80°C
• Material: High heat ABS blend
• Dimensions: 76 × 40 × 78 mm
• Mounting: Shelf or DIN rail socket
• Connector: Single rear-mount 11-pin submagnal, 86CP11
• CE status: CE tested and approved

Use Cases

• Parking barrier control
• Automatic gate vehicle detection
• Residential gate entrances with loop detection
• Commercial parking entrances
• Motorised gates and doors
• Rising bollards and rising kerbs
• Warehouse vehicle access points
• Industrial control systems
• Directional vehicle detection using A-B logic

Compatibility and Installation Notes

The NORTECH PD232 Loop Detector is compatible with access control systems, automatic barriers, motorised gates, and door automation panels that accept relay outputs from a 230V AC dual channel inductive loop detector. Installation requires correctly designed road loops, proper loop wiring, suitable frequency selection, relay output configuration, and safety integration with the gate or barrier control panel. Professional installation is recommended because incorrect loop geometry, poor cable insulation, or wrong sensitivity settings can cause false detection, missed vehicles, or unsafe barrier movement. For more technical setup details, refer to the official 3-Series product data.

Packing Includes

• 1 × NORTECH PD232 Dual Channel Loop Detector
