CAME FROG PLUS Swing Gate Motor

Product Overview

CAME FROG PLUS Swing Gate Motor is an irreversible underground 230 V gearmotor with encoder and adjustable leaf-closing for swing gates up to 5.5 m per leaf and up to 700 kg. Designed for heavy swing gate automation, the official model 001FROG-PM4 offers concealed installation, smooth movement, and secure gate control for Abu Dhabi properties. Its IP67 protection rating supports outdoor underground installation, while the encoder helps manage gate travel and obstruction detection. This motor is suitable for large residential, commercial, and high-use entrance gates where a discreet underground automation system is required. (CAME)

Key Features and Technical Specifications

• Brand: CAME
• Product range: FROG PLUS
• Official model: 001FROG-PM4
• Product type: Irreversible underground swing gate gearmotor
• Power supply: 230 V AC, 50/60 Hz
• Motor power supply: 230 V AC
• Maximum leaf length: 5.5 m
• Maximum leaf weight: 700 kg
• Absorption: 2.1 A
• Power: 500 W
• Maneuvering time at 90°: 30 seconds
• Cycles per hour: 10
• Operating temperature: -20°C to +55°C
• Motor thermal protection: 150°C
• Protection rating: IP67
• Encoder: Yes
• Adjustable leaf-closing: Yes
• Torque: 800 Nm
• Maximum leaf opening: 110°
• Compatible control panel listed by CAME: 002ZM3EP
• Foundation box and release devices: Listed by CAME as accessories, not confirmed as included with the motor

Use Cases

• Villa underground swing gates
• Residential entrance gates
• Commercial swing gate systems
• High-end gated entrances
• Parking entrance swing gates
• Heavy-duty swing gates requiring concealed automation
• Industrial access gates where gate size and weight match the motor limits

Compatibility and Installation Notes

CAME FROG PLUS Swing Gate Motor is compatible with swing gates up to 5.5 m per leaf and 700 kg when the gate structure, underground foundation box, hinges, electrical wiring, drainage, and safety accessories are correctly prepared. Installation should include safe 230 V wiring, correct motor alignment, compatible control panel setup, photocell safety devices, encoder configuration, and final force testing. Professional installation is strongly recommended because underground motors require accurate foundation placement, water protection, mechanical stop adjustment, and safe commissioning. For more technical information, check the official CAME product page.

Packing Includes

• 1 x CAME 001FROG-PM4 FROG PLUS underground gearmotor
